at the centre, and not on one where Fig. 409lies flush against the central arm as in Fig. 416. UNDOING THE PUZZLE. To take the puzzle to pieces all that is required is toturn the key half round and push the other two crossbars on that arm towards the outer point. The cross barsbelow may then be… … Fig. 418. Fig. 419. Puzzle Dovetail Joint. 193 Joints in Woodwork
