Fig. 208. Studs Beveled to Fit UnderSide ef Rafter Fig. 209. Cutting Studs for PartitionRunning Parallel to Rafter stick, the distance K Ris just 4 inches or one-third of the run of therafter, and consequently the distance R N is just 3 inches, or one third of the rise of the rafter. In the case of…
