Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 282
Fig. 305. Section throughSill at Outside of wall Fig. 306. Sill Details Show-ing Use of Apron the side or jamb of the window shown in Fig. 304, Here, A is asection through the vertical studding at the sides of the rough open-ing, B is the outside architrave with the molding C attached to it,F is…
Architecture · Building
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
