un. By takingthese figures, therefore, on the square, 9 inches on the tongue and 12inches on the blade, marking along the tongue will give the plumb cut,and marking along the blade will give the heel cut. Bevels 3 and 4 are the plumb and heel cuts for the hip, and areshown to have the length of the…
