Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 64
Fig. 29. Iron-Bottom Smooth Plane … Fig. 30. Sections of Wood-Bottom and Iron-Bottom Smooth Planes No. 1 is the plane iron, and should be made of steel, well temperedand ground. It should be throughout of the same thickness. No. 2 is the plane iron cap, also of steel, the purpose of which is toprotect the plane iron. No. 3 is the…
