Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 138
—- … Figure 64 with one point of a longer tram, called a wheel tram/set in center C describe the arc A on the tire of thewheel. Next turn the wheel ahead as indicated bythe arrow until the cross head has passed the limit ofits forward travel and has receded on its return strokefar enough to bring the…
Locomotives
