pin was now pulling instead ofpushing the crosshead. The result of this would havebeen an error in the location of the arc B and also ofthe point H. But by pulling the crosshead back pastarc G and then reversing the motion and allowing thepin to push the crosshead until the dead point H waslocated,… … COCD «© VALVE SETTING 141 extreme back notch, so as to take up all the lostmotion in the valve gear while backing up. Nowstart to pinch the engine back, and with one point ofthe wheel tram in center C, watch the center H andwhen it comes exactly under the other point of thetram, stop. The engine is… Locomotives
