Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 138

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 138
edetermined by the lugs on thepattern chain. The pattern chain is operated by the cam M* on 118 KNITTING 105 the take-up arm, which raises the chain driver lever each revolution,and by means of a pawl lever, moves the chain ratchet andsprocket ahead one tooth, unless prevented by the idler ratchet,… … Fig. 48. Frame and Take-up. plate, which carries a bearing for the pinion shaft N\ on the lowerend of which is a pinion N, meshing with the bedplate gear N. Onthe pinion shaft is fixed a single-toothed clutch N^, and a worm N*,journaled on the same shaft. The take-up arms P are supported ontop of…

Textile fabrics · Textile industry
