Figure 64 with one point of a longer tram, called a wheel tram,set in center C describe the arc A on the tire of thewheel. Next turn the wheel ahead as indicated bythe arrow until the cross head has passed the limit ofits forward travel and has receded on its return strokefar enough to bring the… … VALVE SETTING t^9 ihe point of the tram, one point of which is set incenter F. Now reverse the motion and pinch thewheels slowly backward until the arc G comes directlyunder the point of the tram. Then stop, and with thew^heel tram set in center C scribe an arc B on the tire,as indicated in Fig.…
