Id/am 7 H FIG. 338. A CONVENIENT GAUGE FOR SETTING THE ECCENTRIC CRANK In Fig. 337 the eccentric and admission valve circlesare shown at different cut-offs where each set of linesand circles is governed by the same explanation as thoseof Fig. 336, where the admission points S, S,1 S2, S3,… … 762 LOCOMOTIVE ENGINEERING
