Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 834
ng tube. 9—Delivery tube.10—Line check valve.II—Stop ring. 12—Overflow valve complete.13—Water valve complete.14—Starting lever.15—Overflow nozzle. The steam pipe leading from the dry steam space ofthe boiler is connected to the top of the injector abovesteam, valve 5. The water or suction pipe is… … 778 LOCOMOTIVE ENGINEERING
