hangeablewith all other lifting injectors in common use, the sizesand location of the connections being similar. Operation. To operate the Ohio injector open water-valve 13 and pull out lever 14 a short distance. Thisunseats steam valve 5 and allows steam to pass throughprimer nozzle 16 through… … O Bi o O 52 LOCOMOTIVE INJECTORS. which allows the water to enter chambers WW, takingthe course of the steam from primer jet 16. When wa-ter is flowing freely from overflow 15, lever 14 shouldbe pulled back its full stroke, or to its extreme travel.This opens steam valve 5 to its maximum, and…
