, theblows coming in the direction of the arrow. Further shaping is doneas indicated at B. To square up the end of the nose of the tool, it isworked l)ackward and forward as indicated at C. The tool is finisiiedbv trimming off the end to tlie proper angle with a hot chisel and touch-ing it up with… … Fig. 12.5. may Ije started by making a fuller cut as showm at A. The end x is thendrawni out with a fuller into the shape B. After smoothing up witha set hanuner the blade is trued into shape along the dotted lines at C.The tool is finishetl by giving the proper ojfsd to the top edge oftlie blade.…
