56 MACHINE SHOP WORK. in Fig. 78 has a guide to hold the work at right angles to tliedie, but die stocks are often made without this convenience. The split form of die, generally known as the janilMlie( shown in Fig. 79 ), can be easily shar|)ened, lias inilimited ad-justment for size, and cuts the… … It is made in .sizes up to two inches, and is for liaud nperatirxionly. The Ijolder for this form of die is called a screw plate,Fig. 80. These are not furnished with guides for the work. Cutting Pipe Threads. Another comnicm form of threadcutting is that on wrought-iron pipe. The pipe thread is…
