perly adjusted, andthe carriage U moved along the bed. This movement is accom-plished by means of gearing, which is jlaced behind the apron oftlie carriage, and driven by the shaft upon whicii the cone pulleyK is keyed. The driving gear meshes with a rack beneath theupper ledge of the bed.… … 79 66 MACHINE SHOP WORK. Tlie tool is fed to tlie work ami withilniwii from itliy turningthe cross feetl liamlle W. This drives, I>y means of the serewandnut, the cross slide X. This arningemeut permits any desiredtransveree or longitudinal position of tlie tool. The motion of thecarriage is…
