Fiir. 119. Fiir. 150. Tlu! pattern for this casting is represented by Fig. 150, inwhich it is seen that, unlike Fig. 140, the body and core prints areperfectly straight, a slight draft VV inch to 12 inches being givei?to tlie ends of the pattern and to the ends of tlie core prints only.A slight…
