wid(>, and tht; rim containingthe groove is connected with the hub by a solid web I inch inthickness, and having four or six holes, each 1 inch in diameter,this web taking the place of arms. If there is to be no fiitish onthe sheave, as is usual, the only allowance to be made on the pat-tern,… … Fi^^ 159. in sectors, six, eight or more in number, according to the size ofthe sheave (see Fig. 160). The sectors are fitted by hand or on thetrimmer, the ends are glue-sized, and when the sizing is dry thejoints are carefully scraped smooth, and the whole glued together.After drying for fonr or…
