Fit?. 239. … Fig. 211. Fig. 240. of teeth. With a try square and very sharp awl draw lines throughthe points obtained by the spacing as shown in Fig. 240. Shouldthe teeth be of moderate size, say 3 pitch or less, the tooth blocksshould be glued on so as to meet each other on the rim of thewheel as shown in Fig.…
