ustbe taken into consideration when designing a cam. Plate Cams. Fig. 35 shows a plate cam designed to raiseand lower the follower P with uniform motion. The point of Pis raised from A to e while the cam turns ricrht-handed throuc-htwo-thirds of a revolution, and is lowered again to its original… … To design such a cam, draw a circle with O as a center andpassing through A. Since the raising of P is to take place duringtwo-thirds of a revolution, right-handed, find a point E on the cir-cumference of the circle, such that the arc AHE shall be § of thewhole circumference, thus leaving arc ACE…
