Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 46
the dotted lines in Fig. 46. Thisinsures a shearing cut, which, with care, evenwhen the material is cross-grained, will pro-duce a smooth and even surface. As an exercise for acquiring tlie free useof the paring chisel, there is nothing better forthe beginner than the simple half-laj) jointshown in… … 33 26 PATTERN MAKING The two dove-tail joints shown in Fig. 48 may be attempted,after having succeeded with the half-hii:);and these exercises shouldbe continued by the student until such control of thechiselisat-tained that this and siiiiilar work can hv done with ease and certainty.For laying out…
Mechanical engineering -- Dictionaries
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
