nd ona pump of the type chosen, ratiier than through any radical changeof construction as to the body of the machine. Hence the studyof a steam pump may well precede that of higher forms of thesteam engine. It is hoped that the study will so interest the stu-dent that he will be led to further… … IMECIIAXICAL DRAWING. 11 lined. The power end of tlie macliine introduces us to the steamengine; the load end is the beginning of the engineering of pump-ing maclunery. Rating of Pump. A steam pump is rated by the bore of itscylinders and length of stroke, all being given in inches. A10 X 8i X 12…
