pt through the information which the drawing gives on itsface. This requires that the di-aftsman should [uit himself in theworkmans place, and forestall, by the explicit nature of his draw-ing, all possible questions which may arise in the shop. In thisway only can he hope to avoid errors of… … MECHANTCAL DRAWIXa. 19 1 been adopted is 18 X 24 inclies trimming size, with J incli margini all round, so that the working space is 17 X 23 inches. • The rec-tiingle for the title is to be laid ofE 2i X 4 inches in the lowerriglit-liand corner, and must never be altered, either in size orposition.…
