cated ; also that the trapezoid in most cases would be l)iit littledifferent from a true rectangle. Hence the error will be butslight if the average cross-section of the tooth be taken to repre-sent its strength, and the calculation made accordingly. 33 4 … 335 130 MACHINE DESIGN Fig. 45 shows a bevel-gear tooth with the average cross-section in dotted lines. For the purpose of calculation, the assunip.tion is made that the section A is carried the full length of theface of the gear, and that the load which this average tooth mustcarry is the…
