down upon the shaft. Several forms ofcap bearings are illustrated in Figs. 80, 81, and 82. MAnilNE DEST(4N 179 Large engine shaft bearings have special forms of adjustmentby means of wedges and screws, whicb take up the wear in alldirection?, at the same time accurately preserving the alignmentof… … Fig. SO. Fig. 81. new one inserted, the e.\-act alignment being maintained, as theoutside will be concentric with the original axis of shaft, regard-less of the wear which has taken place in the bore. The lubrication of bearings is a part of the design, in thatthe lubricant should be intro-duced at…
