An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 141
^ heavier and stiffer. Tlie arms. A andC, are connected to the bend by a stud, F, which passes through aslot in the bend. The movement, endwise, is obtained by havingthe slot in the bend instead of the arm. The center arm, B, isnot fastened to the bend, bnt acts as a support for it. A pin, E, … pR tJ3 in tbe arm, prevents any circumferential movement of the bend.The arms are all made in two pieces, partly for convenience inmanufacturing and in order to set them alike when the card isfirst erected. Adjusting screws, L, are provided for the two end 125 88 COTTON SPINNING. ones, which, afte^…
