An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 202
and thenipper cam lever, J^. The last named carries a roll, J-*, that runsin a groove, T^, in the face of the nipper cam. The nipper cam lever, J^, is nnide in two parts which enablesa very fine adjustment to be made by means of the screws, T* andT^. The part carrying the screws is keyed to the… … 180 COTTON SPINNING. 141 rods, L^. The nipper cam mukes one revolution to one of thecylinder and, at each revolution, the opening and closing ofthe nipper and cushion plate takes place which corresponds to themovements of the cylinder, To follow these moveniQiits, Figs. 117, 118, 119 and 120liHve…
