Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 323

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 323
, kf, to rise and the cutterto swing away from thecenter of the lag screw,thus forming the taperpoint. A straight por-tion of n then forms theparallel portion of thelag screw, and a furtherrise allows the cutter toclear the screw entirely,when it drops out fin-ished, and the carriageruns back,…

Mechanical movements
