Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 212
s shown by the relativ e positions of a dark spot marked upon thegears in Figs. 127, 128 and 129. 189 1.-.0 COTTON SPINNING. The completion of the revolution of the cams is shown inFig. 130, The cam roll has moved from C back to A and thenose of the cam, A^, has come into contact with the cam roll,… … Fig. 131. Elevation showing Lifting Cain. cam, the pawl will drop into notch IV. The point, marked by thedark spot, has advanced in the same proportion as the notchedwheel, as will be seen b}^ its position above the pinion. The detaching rolls turn backwards at about li bj the tim-ing dial and…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
