H o %^ m B < o W CO X g I-] &3 COTTON SPINNING 257 changes in speed are made by having a different number of teeth ineither the upper or lower sprocket gear. The binder pulley, T®,which is carried by an arm, V^, is for taking up the slack of the chain ■when necessary. To change the draft,… … TWIST GEARSTUD 6EARDRUM GEAR- Fig. 320. Diagram of Twist Gearing. teeth are shown. These may be changed to twenty and sixty-fourteeth or thirty and one hundred four teeth. The back roll gear shown has fifty-six teeth but it is also suppliedwith fifty, fifty-four or fifty-five teeth. The regular…
