Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 279

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 279
hat the cone belt is moved. When the attendant wishes to stop the machine, the shippei* rod 247 H)G COTTON SPINNING is moved in the op])()site direction from that inthcated by tlie arrowand the belt is shifted onto the loose pulley. This movement does notdisconnect the train of <^ears, between… … Fig. 17.3. Tension Gearing. wait for this stop motion to operate before doffing, it acts a.s a safe-guard, for, if the frame is allowed to run too long, there is danger ofthe builder jaws coming together, which often results in stripping thebuilder screw. There is also some difficulty in doffing,…

Textile industry · Textile fabrics
