Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 94

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 94
e with the teeth of the worm gear, the sleeve being drivenby the lugs projecting between the arms of the dog. Another style of evener, which is applied to intermediate orfinisher pickers, is shown in three views, a section, an end elevationand a partial phm in Fig. 40. On the end of the evener… … Fiff. ,39. Clutch and Worm Gear. 84 COTTON SPINNING. 4() by the gears, N and P. The cotton passes on the feed apron, A,and between the evener roll, and the pedals, C, then between thefeed rolls, E and G.These pedals, eight innumber, are made Avitlione end a flat surfaceover which the cottoni3asses,…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
