Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 101
are kept from rising by the friction of the break lever againstthe break pulley. When it has been wound to its full diameter,the attendant presses down upon the break lever, releasing it fromcontact with the break pulley; then the rack can be raised byturning the handwheel, J, on the end of the… … COTTON SPINNING. 55 while the pinion, W, which gears into the rack, K, is connected tothe rack shaft by a lug projecting between the arms of a dog, orcarrier, T, which is keyed to the rack shaft. In the arms of thedog are adjusting screws, T^ and T^, which bear against the pro-jecting lug of the…
Textile fabrics · Textile industry
