Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 193
e inch less in width than those required for thecomb, as they spread some when passing through the draft rolls. The ribbon lapper is provided with two stop-motions, onewhich stops the machine immediately if a lap runs out at the backand one, called a full lap stop-motion, whicli regulates the… … 21 5^ SO Fig. 111. Diagram of Gearing of Ribbon Lapper. face and make three revolutions to one of the five inch calenderroll. The usual speed for the driving pulleys is from 250 to 300R. P. M. The draft of the ribbon lapper is principally between theback and front rolls, but in addition, there is…
Textile fabrics · Textile industry
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
