Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 232
f there are six cans at the back, and the sliver from these cans isdrawn through as one sliver, or doubled six into one, the machineis given a draft of six, so that the weight of the sliver being de-livered is the same as the weight of that from each can. While 209 170 COTTON SPINNING this is the… … Fig. H3. Front Elevation of Drawing Frame Driven from Above. sliver plate, J, through the trumpet, ]^, and between the calenderrolls, E and F. From this point, it falls through the spout of thecoiler, G, and is coiled in the can, H. Stop Motions. The drawing frame is provided with four stopmotions:…
Textile fabrics · Textile industry
