Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 331
ions to eachrevolution of the drum, and this is called relation of drum to whirl.This relation must be known in figuring the speed of the spindle, hencethe following table: Revolutions of Spindle Dia. ot whirl 7 drum 8 arum 9 drum . - 3,, 8.12 9.20 10.72 7.58 8.6i 9.94 7.05 • 8.10 9.45 1 6.48 7.18… … COTTON SPINNING 257 changes in speed are made by having a different number of teeth ineither the upper or lower sprocket gear. The binder pulley, T,which is carried by an arm, Y, is for taking up the slack of the chainwhen necessary. To change the draft, various combinations are used. In…
Textile fabrics · Textile industry
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
