for it sometimes happens that one hook is lifted while theother is pressed back by the cylinder, so that the same thread willnot be lifted for the ne-xt pick. The bottom of the hook is made in the form of a caj)ital let-ter V. The reason for this is that it saves a considerable amount 300 JACQUARD… … bottom of the hook passes. Fig. 23 shows the position occupiedby the hooks when one hook is lifted and • the other hook (whichpasses through the same needle) is pressed off. The dotted linesshow the original positions of the hooks. 301 24 JACQUARD MACHINES In addition to the added friction on the…
