Draw frames and fly frames : being a practical treatise on the above machines (1898)
Thornley, T. (Thomas) · Manchester : A. Heywood · leaf 371
Cone End Wheel. G Driving Wheel for Bob-bins. H Driving Wheel for Spin-dles. I Back Roller Wheel. J Sun Wheel. K Outside Spindle Wheel. L Skew Gear Wheel forSpindles. M Spindle Bevel Wheel. N Outside Bobbin Wheel. P Skew Gear W^heel for Bobbins.Q Bobbin Bevel Wheel.R Jack Shaft Wheel.S Lifter Bevel… … 6 3^3 CHANGE PLACES. A Change for Draft. Wheels 35 to 60 teeth. B ,, Twist. ,, 26 to 48 ,, C „ Winding (Star Wheel). Wheels 10 to 50 teeth.D Change for Traverse (Lifter Wheel) Wheels 16 to 26 teeth.E Proportional to diameter of empty bobbin (Jack Wheel). Wheels 15 to 30 teeth.F Traverse and…
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
