Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 144

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 144
and 71, is called the scrolladjustment. The bend, D, -s supported at three points by arms,A, B untl C, instead of five, as in the first one shown, the bend 184 COTTON SPINNING. S7 being made proportion a tcly heavier and stiffer. The arms, A andC, are connected to the bend by a stud, F, which… … be in the arm, prevents any circumferential movement of the bend.The arms are all made in two pieces, partly for convenience inmanufacturino and in order to set them alike when the card isfirst erected. Adjusting screws, T, ai-e provided for the two end 125 88 COTTON SPINNING. ones, which, afte^…

Textile industry · Textile fabrics
