across the apron in a diagonal direction. Attached to this belt isthe dog 4, which is about three inches long and works in the slotof the carrier 5. The carrier works upon the shaft 6. The sliver1 passes through the rolls 2, and is laid on the feed apron by themotion given to the carrier 5 by the… … eno cama KO Q« WOOLEN AND WORSTED SPINNINCx 123 travels on the rod 6. Two latches marked 8 in Fig. 80 are liftedby the carrier and fall down into the loop formed by the sliverwhen the carrier returns, and thus hold it from drawing back asthe next layer is placed on the apron. Apron 1 should…
