Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 594
Fig. 423. Fig. 424. Fig. 423.—Water column, try-cocks and water glass of the Locomobile Carriage. Thewater column is connected to the boiler at top and bottom, as shown. The continua-tion of the lower pipe to the right leads to the steam gauge. Fig. 424.—Type of check valve for a water glass. As…
Automobiles
