Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 65

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 65
is given in the diagram Fig, 26 ; the arrows on n 42 WOOLEN AND WORSTED SPINNING. the rolls, pulleys, etc., indicate the direction in which they revolvewhile the groups of arrows show the direction of the air current.A is the apron, B the feed roll, C the cylinder, D the worker, Ethe fan, F the…

Textile fabrics · Textile industry
