An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 112
t must be changedfor one with a larger crank;otherwise, in a sateen cloth of120 picks per inch or more, avery small shuttle will have tobe used or the side ends willbe broken frequently. Thenagain a stronger pick is re-quired to force the shuttleacross the lay before the shedcloses. These… … Fig. 52. Sectional Pick Cam. SHEDDING MOTION. The build of the sheddirig cams greatly influences the rest ofthe working parts of the loom. Too little attention is given to theseessentials in consideration of the return which is expected fromthem. It is impossible to get good returns from an…

Textile fabrics · Textile industry
