LVE PROPORTIONS. Take for example any extreme port opening—say1J inches for a cut-off at § stroke ? We see by a glance at the table that the travel mustbe 4 times as great as the port opening, while the lapmust be once the port opening, thus giving instantly the A f Travel = 6 inches. Lap = lh… … PART III. GENERAL PROPORTIONS MODIFIED BY CRANK AND PISTON CONNECTION. OEANK AND PISTON CONNECTION. Thus far we have confined our attention to a form ofconnection called the slotted cross-head, and have beenable therewith to deduce laws governing the proportions ofthe various parts of the valve, as…
