An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 25
bars on the mangle gear,because there is a loss of one tooth as the small pinion passesround the end of the gear; and this occurs at both ends. For example: Rev. of MainDriving Shaft. 300 X Pulley onMain Shaft. PuUey on SmallMachine Shaft. SmallPinion. X 2f X 6 10 Pulley onMachine Shaft. X 101 X 62…
