Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 29
12 WARP PREPARATION. tiers, or rows of spools, can be changed to suit the altered bays.This is necessary when the angle of the bay is changed, becauseas the yarn is drawn off the spool, the added tension spoils theelasticity, if it does not break it. … Expansion Reed. From the creel the yarn passes throughan expansion reed. The purpose of this reed is to \/ary the widthof the ends from the creel so that it will conform to the width ofthe beam on which it is to be placed. 20 WARP PREPARATION. 13 nensuring Roll. From the reed the ends pass over…
Textile fabrics · Textile industry
