Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 349

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 349
n machine, it isnecessary to have two different sizes of lifting cranks to allow ex-tra lift for the difference in length of the levers, owing to one ofthe levers working on the inside of the other. The length oflevers used is about 30 inches for the longer end, from fulcrum toconnection of lifting… … crank is made so that the one with the 12-inch stroke is attachedto the shorter lever, and the 10-inch stroke operates the longer lever.The cradle lever lift is used only on machines that have theharnesses attached to them by the cross tie system, because by thestraight tie system the machine is…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
