Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)
Chicago : American school of correspondence · leaf 129
Fig. 63. Diagram for % Dwell. … Fig. 64. Diagram for % Dwell. 109 100 WEAVING. To give the correct shed, tlie Lirger cam controls the treadle for theback harness, and the cam with the largest depression is placed overthe front-harness treadle. The front liarness is also connected withthe smallest set collar on the harness roller.…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
