Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)
Chicago : American school of correspondence · leaf 343
double actionmachine. The shedding motion is obtained by means of a double crankhxed on the end of the pick cam shaft, and to which the long lift- 302 JAC(^UAUl) .AIACHINES 25 ino; rods are attached. This is shown in Fig. 25. Cams havebeen used to take the place of the double crank, so as to allow… … cam motion was proven to be somewhat detrimental, owing to thequick rise and fall of the harnesses, which causes the lingoes tojump and to be constantly breaking off. The neck cords also wereconstantly breaking The cam movement could be used success-fully with a jacquard that had not many harness…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
