Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 267

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 267
relativepositions during the knitting operation, as is necessary in machinesusing sinkers, there being more or less lost motion between the sinkercam ring and the cam cylinders during the changes in reciprocatingknitting. 28b 218 KNITTING The Jacks a^ which take the stitches as they are formed… … Fig. 135. Skeleton Cylinder. top of the needle cylinder, are contained the jacks, free to be actuatedhorizontally in the groove in the jack cam ring a. The ring b issecured to the needle cylinder by means of a set screw b^. In circular knitting the cam for moving the sinkers is so locatedwith…

Textile fabrics · Textile industry
