Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 325

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 325
adjustment of the needle-bars. It is very importantthat the needles should always be in exact co-operating position withthe sinkers; and it will readily be understood by referring to theillustration, that the double bolt and jam-nut of this double-armedneedle-bar crank furnish accurate means for… … Fig. 183. Draw-Cam Shaft Brake. shaft takes place—in other words, as soon as the machine commencesto narrow. In nearly all other machines this stopping of the draw-cam shaft is done by a key pushing in between the teeth of the bevelgear on the cam-shaft. This improved brake works with a steel…

Textile fabrics · Textile industry
